51
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
69157 1 ROPS Assembly
2 N/S 1 • Base, ROPS
3 5003595 1 • Plate, Rear Backing
4 5003596 1 • Bracket, Seat Belt
5 5000629 1 • Seat Belt, 60”
6 400370 2 • Screw, 7/16-20 x 1” Hex Head
7 452010 2 • Flat Washer, 7/16
8 444730 2 • Locknut, 7/16-20 Hex Center
9 400408 8 • Screw, 1/2-13 x 1-1/2” Hex Head
10 446154 12 • Lockwasher, 1/2 Heavy
11 443118 12 • Nut, 1/2-13 Hex
12 400420 4 • Screw, 1/2-13 x 3-1/2” Hex Head
13 5003598 1 • Decal, Seat Belt Warning
14 5003597 1 • Decal, Structure Warning
15 4111942 1 3WD Valve See 39.1
16 400124 1 Screw, 1/4-20 x 2-1/2” Hex Head
17 452004 3 Flat Washer, 1/4
18 444708 2 Locknut, 1/4-20 Hex Center
19 400126 1 Screw, 1/4-20 x 3” Hex Head
20 360343 1 Clamp, Harness Seat Switch Harness
21 354080 1 Clamp, Hose Return Hose
22 345671 1 Clamp, Hose Reel Return Tube
