Page #53 background imageLoading...
Page #53 background image
53
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
4138501 1 Steering Cylinder
4137139 1 Seal Kit
2 443820 2 Nut, 1/2-20 Hex
3 3010485 2 Ball Joint
4 353914 4 Wheel Bolt, 1/2-20 x 3/4”
5 1001129.7 1 Steering Fork Includes cup portion of Item 9
6 471231 1 Grease Fitting, 1/8 NPTF
7 400414 5 Screw, 1/2-13 x 2-1/4” Hex Head
8 444758 2 Locknut, 1/2-13 Hex Center
9 5002916 2 Bearing, Cup and Cone with Seal
10 452018 1 Flat Washer, 3/4”
11 445676 1 Nut, 3/4-16 Slotted Hex
12 460054 1 Cotter Pin, 3/16 x 1-3/4”
13 400408 1 Screw, 1/2-13 x 1-1/2” Hex Head
14 4182425 1
Wheel Motor, 11.9 in
3
See 40.1
15 554780 1 Key
16 554779 1 Nut, 1-20 Slotted Hex
17 447030 1 Lockwasher, 1” External Tooth
18 3008482 2 Spacer
19 220290.7 1 Hub, Wheel
20 443118 4 Nut, 1/2-13 Hex
21 446154 4 Lockwasher, 1/2 Heavy
22 360111 1 Valve, Inflation
23 4236061 1 Tire, 20 x 10 - 8 Grass Master
24 4236021 1 Rim, 8 x 7
