57
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
4141036 1 Radiator
2 4150717 1 Bracket, Front Radiator Mount
3 4140846 1 Shroud, Fan
4 362535 9 Screw, M6-1 x 16 mm Hex Head
5 446128 9 Lockwasher, 1/4
6 452004 9 Flat Washer, 1/4
7 452008 6 Flat Washer, 3/8
8 4197181 2 Weater Strip
9 4150418 1 Bracket, Rear adiator Mount
10 4197180 2 Weather Strip
11 4199660 1 Bracket, Upper Radiator
12 553887 4 Washer, Cup
13 443810 2 Nut, 3/8-16 x 3/8”
14 460312 2 Hair Pin
15 4150598 2 Screw, 3/8-16 x 2” Special
16 553886 2 Cushion, Radaitor
4141392 1 Radiator Hose Kit
17 319914 4 • Clamp, Hose
18 N/S 1 • Hose, Lower Radiator
19 N/S 1 • Hose, Upper Radiator
20 844945 AR Trim, Seal 30 Ft. Length, Cut to 11”
To Next Page
