59
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
REF 1 Engine and Pump Assembly See 15.1
2 3004523 4 Mount, Isolation
3 400186 8 Screw, 5/16-18 x 7/8” Hex Head
4 446136 12 Lockwasher, 5/16 Heavy
5 400190 1 Screw, 5/16-18 x 1-1/4” Hex Head
6 452006 2 Flat Washer, 5/16
7 361005 3 Screw, M8-1.25 x 25 mm Hex Head
8 346006 1 Cable, Engine Ground
9 444718 2 Locknut, 5/16-18 Hex Center
10 400272 4 Screw, 3/8-16 x 2-1/4” Hex Head
11 3004526 4 Washer, Isolation Mount
12 446142 4 Lockwasher, 3/8 Heavy
13 443110 4 Nut, 3/8-16 Heavy
14 4129589 1 Universal Joint See 20.1 for Pump Connection
554663 2 • Cross and Bearing Kit
To Next Page
