61
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
4189580 1 Engine, Kubota D722-E3B
2 5002644 1 • Cartridge, Engine Oil Filter
3 4127309.7 1 Bracket, Front Engine Mount
4 2811637.7 1 Bracket, Rear Engine Mount
5 452008 8 Flat Washer, 3/8
6 363485 8 Lockwasher, M10
7 362263 8 Screw, M10-1.25 x 25 mm Hex Head
8 2810499.7 1 Pulley, Reel Pump Drive
9 446136 12 Lockwasher, 5/16 Heavy
10 2810545 5 Screw, M8-1.25 x 30 mm Button Hd
11 2809727 1 Clutch, Reel Pump REFERENCE K2, See 42.1
12 4130754.7 1 Bracket, Pump Pivot
13 4174020 1 Pump, 3 Section Gear See 35.1
14 5001437 1 Key, 5/32 x 3/4” Square
15 400226 4 Screw, 5/16-24 x 1” Hex Head
16 3001950 1 V-Belt, Reel Pump
17 364501 1 Temperature Sender REFERENCE U5, See 42.1
18 446128 1 Lockwasher, 1/4
19 361001 1 Nut, M6-1 Hex
20 4141024 1 Fan, Engine Cooling
21 4125492 1 Spacer, Fan
22 363448 4 Screw, M6-1 x 35 mm Hex Head
23 446130 4 Lockwasher, 1/4 Heavy
24 452004 4 Flat Washer, 1/4
25 4210160 1 Spacer, Pump Mount
26 457016 6 Spacer, Pump Pivot
27 361005 2 Screw, M8-1.25 x 25 mm Hex Head
28 452006 3 Flat Washer, 5/16
29 400190 1 Screw, 5/16-18 x 1-1/4” Hex Head
30 443106 1 Nut, 5/16-18 Hex
To Next Page
