67
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
1002019.6 1 Tank, Hydraulic Oil Approximately 4.5 Gallons
2 400424 4 Screw, 1/2-13 x 4-1/2” Hex Head
3 344132 4 Washer
4 446154 4 Lockwasher, 1/2 Heavy
5 443118 4 Nut, 1/2-13 Hex
6 1000973 1 Bracket, Battery
7 2809688 1 Cap, Tank Breather
5003624 1 • Gasket
8 1001148 1 Filter Assembly
9 549597 1 • Cartridge, Filter
10 N/S 1 Battery, 12V Group 22NF REFERENCE B1, See 42.1
11 346361 2 Hook, 1/4-20 J
12 3003444 1 Retainer, Battery
13 452004 2 Flat Washer, 1/4
14 446130 2 Lockwasher, 1/4 Heavy
15 445612 2 Nut, 1/4-20 Wing
16 1001134 1 Fuel Tank Approximately 6.5 Gallons
17 1001311 1 Fuel Shut Off Valve
18 361117 2 Bushing, Fuel Tank
19 325822 1 Hose, 1/4 x 14” Fuel
20 361748 1 Valve, Overflow
21 4179802 1 Cap, Fuel Tank
22 3002397 1 Plug, -10 ORB Magnetic Drain
23 339899 1 • O-Ring, -10 ORB
24 339900 1 O-Ring, -12 ORB
To Next Page
