71
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
3003219 1 Hose, Charge Pump Suction
2 108094-02 2 Clamp, Hose
3 4129590 1 Pump, Hydraulic Traction See 20.1 for Pump Mounting
4 340070 1 Fitting, -10 ORFS x -10 ORB 90°
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
5 2809725 1 Tube, Traction Pump Return
339911 1 • O-Ring, -10 ORFS
339908 2 • O-Ring, -4 ORFS
6 1001503 1 Hose, Traction Pump Return
7 339989 1 Fitting, -10 ORFS x -10 ORB Straight
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
8 354080 1 Clamp, Hose See 22.1 for Mounting
9 340055 2 Fitting, -4 ORFS x -4 ORB 90°
339908 1 • O-Ring, -4 ORFS
339896 1 • O-Ring, -4 ORB
10 4182425 1
Wheel Motor, 11.9 in
3
Front Left
See 9.1 for Motor Mounting
11 4189920 1
Wheel Motor, 9.6 in
3
Front Right
See 9.1 for Motor Mounting
12 1001488 2 Hose, Wheel Motor Case Drain
13 1001148 1 Charge Filter Assembly See 20.1 for Filter Mounting
549597 1 • Cartridge, Charge Filter
14 340068 1 Fitting, -8 ORFS x -12 ORB 90°
339910 1 • O-Ring, -8 ORFS
339900 1 • O-Ring, -12 ORB
15 1001372 1 Tube, Charge Filter to Pump
16 339983 1 Fitting, -8 ORFS x -6 ORB Straight
339910 2 • O-Ring, -8 ORFS
339897 1 • O-Ring, -6 ORB
17 473142 4 Cable Tie
To Next Page
