73
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
4129590 1 Pump, Hydraulic Traction See 20.1 For Pump Mounting
2 339989 11 Fitting, -10 ORFS x -10 ORB Straight
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
3 2810603 1 Tube, Pump to Upper Motor Port
4 340265 1 Tee, -10 ORFS x -10 ORB Run
339911 2 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
5 2810602 1 Tube, Upper Motor Ports
6 4182425 1
Wheel Motor, 11.9 in
3
Front Left
See 9.1 For Motor Mounting
7 1001495 1 Hose, Upper Tube to 3WD Valve
8 4111942 1 3WD Valve See 10.1 For Valve Mounting
9 1001496 1 Hose, 3WD Valve to Motor Wheel Motor Port (A)
10 4182425 1
Wheel Motor, 11.9 in
3
Rear
See 11.1 For Motor Mounting
11 1001496 1 Hose, Motor to 3WD Valve Wheel Motor Port (B)
12 1001495 1 Hose, 3WD Valve to Lower Tube
13 2810601 1 Tube, Lower Motor Ports
14 340121 1 Tee, -10 ORFS Swivel Run
339911 2 • O-Ring, -10 ORFS
15 4189920 1
Wheel Motor, 9.6 in
3
Front Right
See 9.1 For Motor Mounting
16 2810604 1 Tube, Lower Motor Port to Pump
17 473142 3 Cable Tie
To Next Page
