83
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
122759 1 Cylinder, Hydraulic Lift
554331 1 • Seal Kit
2 554330 1 • Bushing, Bronze
3 364238 1 Pin, Cylinder
4 345700 6 Washer, Shim
5 460052 1 Cotter Pin, 3/16 x 1-1/2
6 1001258.7 1 Crank Bottom
7 307374 1 Washer
8 458038 1 Retaining Ring
9 365106 2 Bushing, Lift Crank Included with Frame
10 463040 1 Key, 1/4 x 1-1/4” Woodruff
11 1001259.7 1 Crank Top
12 415519 1 Set Screw, 5/16-18 x 3/8”
13 3003035 1 Pin, Transport Lock
14 461418 1 Roll Pin, 1/4 x 3-1/2”
15 460335 1 Pin, 1/8 Spring Clip
16 1001271.7 1 Rear Lift Arm
17 3007694 2 • Bushing
18 471216 1 Grease Fitting, Straight
19 2809741 1 Pin, Pivot
20 460096 1 Cotter Pin, 5/16 x 1-3/4”
21 400188 1 Screw, 5/16-18 x 1” Hex Head
22 446136 1 Lockwasher, 5/16 Heavy
23 452006 1 Flat Washer, 5/16
24 443106 1 Nut, 5/16-18 Hex
25 364234 1 Ball Joint, Rod End
26 444780 1 Locknut, 1/2-20 Hex Center
27 443820 1 Nut, 1/2-20 Hex Jam
28 1000956.7 1 Chain, Lift
29 3001905.7 2 Plate
30 3006409 2 Screw, 3/8-16 x 1-1/2” Gr 8 Hex Head
31 452006 2 Flat Washer
32 445799 2 Locknut, 3/8-16 Hex Center For Grade 8 Bolt
33 364149.7 1 Spring, Extension
34 400262 1 Screw, 3/8-16 x 1” Hex Head
35 446142 1 Lockwasher, 3/8 Heavy
36 452008 1 Flat Washer, 3/8
37 3003754 1 Bolt, 3/8-16 Spring
38 443110 2 Nut, 3/8-16 Hex
To Next Page
