93
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
132639 1 Roller, 26” Reel Rear Used on 67114, 67115, and 67116
1 132640 1 Roller, 30” Reel Rear Used on 67123, 67124, and 67125
2 5002831 1 • Tube, 26” Reel Roller Used on 67114, 67115, and 67116
2 5002832 1 • Tube, 30” Reel Roller Used on 67123, 67124, and 67125
3 3003415 1 • Shaft, 26” Reel Roller Used on 67114, 67115, and 67116
3 3003414 1 • Shaft, 30” Reel Roller Used on 67123, 67124, and 67125
4 338647 2 • Seal, Inner Oil
5 500534 2 • Bearing, Cup and Cone
6 3005156 2 • Wear Sleeve
7 3004882 2 • Seal, Outer Oil
8 367029 2 • Locknut, 3/4-16 Hex Jam
9 471214 2 • Grease Fitting, 1/4-28 Straight
10 132680 2 Rear Roller Adjuster
11 412015 2 Set Screw, 5/16-18 x 5/8” Square Hd
12 3007673 2 Housing, Roller Adjuster
13 3000313 4 Nut, 3/4-16 Hex Adjuster
14 400264 8 Screw, 3/8-16 x 1-1/4” Hex Head
15 446142 8 Lockwasher, 3/8 Heavy
16 443110 8 Nut, 3/8-16 Hex
17 3008359 1 Bracket, Left Side Front Roller
18 3008360 1 Bracket, Right Side Front Roller
19 366653 2 Washer
20 207474 1 Shoe, Left Side Reel Skid
21 434002 4 Screw, 3/4-16 x 1-1/2” Hex Socket
22 446174 4 Lockwasher, 3/4 Light
23 554723 1 Wrench, 5/8” Hex Skid Shoe
24 471214 2 Grease Fitting, 1/4-28 Straight
25 207473 1 Shoe, Right Side Reel Skid
To Next Page
