99
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
5001448 1 Stator
2 5001443 1 Drive Shaft
● 3 N/S 1 Oil Seal
● 4 N/S 1 Retaining Ring
5 5001446 4 Sleeve, Bearing
● 6 N/S 1 Gasket, 0.00050 (Silver)
Use gasket same color as original
gasket.
● 6 N/S 1 Gasket, 0.00100 (Amber)
● 6 N/S 1 Gasket, 0.00075 (Gold)
7 5001447 1 Idler Shaft
8 N/S 1 Steel Ball
9 5001441 1 Shear Pin
10 5001442 4 Snap Ring
11 5001445 2 Gear, 1-3/8” Wide
12 N/S 1 Housing, Gear
13 5001444 1 Lee Plug
14 5001449 2 Alignment Pin
15 N/S 1 Dowel Bushing
16 555828 1 Screw, 1/4-20
17 N/S 1 Housing, Valve
● 18 N/S 1 O-Ring
19 2501165 1 Valve Plate
● 20 N/S 1 O-Ring
503504 1 Valve Stem Kit
21 N/S 1 • Valve Stem
22 N/S 1 • Shear Pin
● 23 N/S 1 • O-Ring
24 N/S 1 Roll Pin
25 N/S 1 Plug, 1/16 NPTF
26 N/S 7 Screw, 1/4-20
503503 1 Relief Valve Kit
503502 1 • Relief Valve Cap
27 N/S 1 ••Cap
● 28 N/S 1 • • Copper Gasket
29 N/S 1 • Adjustment Screw
30 N/S 1 • Spring
31 N/S 1 • Poppet
● 32 N/S 1 O-Ring
5002657 1 Seal Kit Includes Items marked ●
