TECHNICAL NOTICE
5
3- The items shown are included with
the Tower Kit and are used in the
assembly.
4- Remove nozzle holders from left
and right branches.
5- Install the nozzle holders with seal
(1) on the Tower Kit nozzle branch (2
and 3). By, placing the nozzle holder
seal (1) in the hole of the Tower Kit
nozzle branch and install the nozzle-
-holder (3).
1
2
3
Kit Tower
nozzle holder
