XP
XP
06 19
N.
P/N
DESCRIPTION
Qty
N.
P/N
DESCRIPTION
Qty
LLM-464
ENGLISH
Attention
Atención
∙ After assembling the sprayer, fill the tank with clean water and pressure-
-check the tank lid, diaphragm, tank bottom, lance and trigger valve
for leakage. Most leaks can be stopped by retightening the appropriate
connections and fittings. Any leakage must be repaired before returning
to service
.
Después de montado, llene el depósito del pulverizador y pruébelo para
eliminar posibles fugas.Conexión de las manguera; diafragma de la tapa;
fondo del depósito; lanza; válvula, etc
.
1 1198800 Washers and lock
rings set (repair) 1
2 1210725 Gasket holder XP 1
3 1168409 Gasket (felt) 1
4 1168407 Piston cup
(Santoprene™) 1
5 1168406 Chamber with
piston cup 1
6 1168404 O-ring ORI-033 1
7 1168405 Chamber cylinder 1
8 1168410 Stainless steel ball 1
9 560573 Lid diaphragm 1
10 1210726
Lid with diaphragm
XP 1
11 1168414 Strainer XP 1
12 1210727 Tank base 1
13 1168397 Base lock 2
14 1211809 Tank XP312 with
lock (white) 1
14A 1211810 Tank XP416 with
lock (white) 1
14B 1200395 Tank XP12 with
lock (blue) 1
14C 1200398 Tank XP16 with
lock (blue) 1
15 883108 Axle with lock 1
16 1197400 Pumping rod XP
(orange) 1
17 495648
Handgrip assembly
1
18 615005 Lever assembly
(orange) 1
19 635664 Strap lock 1
20 1176504 Strap assembly
with adjustment XP
1
21 942193 Screw cap S20 2
22 1168403 Hose assembly XP 1
23 1168418 Filter LP-3 1
24 502757 Strap buckle 2
25 1168421
Lever assembly LP-3
1
26 1168422 Trigger valve nee-
dle assembly LP-3 1
27 1168419
Trigger valve assem
-
bly LP-3 1
28 635276 Elbow with cone
packing 1
29 100131 Lance 601 1
30 1180613 Spring 1
31 592139 Nozzle filter M40 1
32 325787 Blue adjustable
cone nozzle 1
33 942201 Outlet tube 2
34 231845 O-ring 110 2
35 996058 Trigger valve cap 1
36 915744 Screw cap 2
37 1176816 Lance LP-3 assem-
bly 1
