J-200 Series
All North American J-210 & J-220 Convertible Models (60Hz)
120V/15A† 240V/30A† 240V/40A
‡
Circuit Breaker:
15A†, 1-Pole 30A†, 2-Pole
40A
‡
, 2-Pole
Number of Wires: 3 (15A GFCI
Cord US Only*)
4 (Hard Wire
Only)
4 (Hard Wire
Only)
Frequency: 60Hz 60Hz 60Hz
Current Draw: 12A 21A 30A
* All Canadian spas must be hard wired per CSA Canadian standards. (page 4)
†
In 15A/30A configuration, the heater will not operate while the jets pump
is running in high speed. The factory setting is 120V/15A.
‡
In 40A configuration, remove jumper JP1-2 on the board, to allow the heater
to operate when the jets pump is running in high speed.
CAUTION (For 4-wire 240 VAC Heater Operation): Move the red wire
on the main terminal strip (TB1) from position #1 to position #3. Make
certain wires are connected exactly as shown in Figure-D (Page 15)
before applyng power. Failure to do so will result in damage to the circuit
board and /or related components and void the manufactures’s warranty.
Export J-270 & J-280 Models (50Hz)
230V/20A* 230V/30A** 230V/40A***
Circuit Breaker:
20A* 30A** 40A***
Number of Wires: 3 3 3
Frequency: 50Hz 50Hz 50Hz
Current Draw: 15A 23A 29A
*
In 20A configuration, the heater will not operate while either jets pump
is running in high speed. This is the factory setting. Note: pump 2 runs
only in high speed.
**
In 30A configuration, the heater will operate while one jets pump is run-
ning in high speed. Note: pump 2 runs only in high speed.
***
In 40A configuration the heater will operate while both jets pumps are
running in high speed.
11
