Jacuzzi J-220 User Manual

J-200 Series
GRN
WHT
WHT
BLK
BLK
BLK
RED
1
2
3
Figure-C
TB1
to Circuit
Board
Power In
GRN
WHT
WHT
BLK
BLK
BLK
RED
RED
RED
1
2
3
Figure-D
TB1
to Circuit
Board
Power In
Move Red
Wire Here
North American Convertible Models:
120/240 VAC, 3-Wire Connection 60Hz
North American Convertible Models:
120/240 VAC, 4-Wire Connection 60Hz
CAUTION (For 4-wire 240 VAC Heater Operation): Move the red
wire on the main terminal strip (TB1) from position #1 to position #3.
Make certain wires are connected exactly as shown in Figure-D before
applyng power. Failure to do so will result in damage to the circuit board
and /or related components and void the manufactures’s warranty.
BLK
RED
RED
RED
BLK
BLK
1
2
Figure-E
TB1
to Circuit
Board
Power In
Green
TB3
1
2
BLUE
BLUE
BROWN
BROWN
Figure-F
TB1
to Circuit
Board
Power In
Green
TB3
North American 240V Models:
120/240 VAC, 3-Wire Connection 60Hz
All Export Models:
230 VAC, 3-Wire Connection 50Hz
Install control box door and screws and reinstall the cabinet side panels.
Congratulations! You are now all set to get your new spa ready to use. Simply
follow the step-by-step procedure in Section 8.0, before long, you will be enjoy-
ing your first glorious experience in your Jacuzzi J-200 Series spa.
10.
15
