J-200
14.0 Error Conditions and Messages
Your spa has a self-diagnostic control system. The system will
automatically display the following if a problem is detected. Always
insist on genuine Jacuzzi replacement parts.
A. General Messages
1.
Priming Mode - M019: Each time the spa is powered up, it will enter
a Priming Mode. The purpose of Priming Mode is to allow the user
to run each pump and manually verify that the pumps are primed
(air is purged) and water is owing. This typically requires observing
the output of each pump separately and is generally not possible in
normal operation. Priming Mode last about 4 minutes, but you can
exit it earlier by pressing any Temp button. The heater is not allowed
to run during Priming Mode.
2. or
Water Temperature is Unknown: After the pump has been running for
1 minute, the temperature will be displayed.
3.
Too Cold - Freeze Protection: A potential freeze condition has been
detected, or the Aux Freeze Switch has closed, and all pumps are
activated one at a time. All pumps are ON for at least 4 minutes
after the potential freeze has ended, or when the Aux Freeze Switch
opens. This is an operational message, not an error indication.
Note: In some cases, pumps may turn on and off and the heater may
operate during Freeze Protections.
4.
Water is too Hot (OHS) - M029: DO NOT ENTER THE WATER.
One of the water temp sensors has detected spa water temp 110°F
(43.3°C) and spa functions are disabled. System will auto reset when
the spa water temp is below 108°F (42.2°C). Check for extended
pump operation or high ambient temp.
WARNING: RISK OF HYPERTHERMIA (OVER-HEATING)
CAUSING SEVERE INJURY, BURNS, OR WELTS.
!
B. Reminders Messages
1.
Change Water: The change water timer has expired. The spa needs
to be drained and relled. The display will alternate between “CHNG
WATR” and the normal display. The timer for this reminder will need
to be reset, page 38.
51
