J-200
B. 1-Pump Models
ON Position
S1
SWITCH
OFF Position
NOT ASSIGNED 8 NOT ASSIGNED
NOT ASSIGNED 7 NOT ASSIGNED
MEMORY RESET* 6 STORE SETTINGS*
SPECIAL AMPERAGE RULE ON 5 SPECIAL AMPERAGE RULE OFF
5 MIN HTR COOL DOWN (GAS) 4 1 MIN HTR COOL DOWN (ELEC)
ADD 2 HS PUMPS WITH HEAT 3
DON’T ADD 2 HS PUMPS W/
HEAT
ADD 1 HS PUMP WITH HEAT 2 DON’T ADD 1 HS PUMP W/HEAT
TEST MODE ON 1 TEST MODE OFF
*Switch #6 should be set to OFF upon nal installation. All unused switches
should be OFF.
BREAKER
DIP SWITCH NUMBER
1 2 3 4 5 6 7 8
15A* OFF OFF OFF OFF OFF OFF OFF OFF
30A OFF OFF OFF OFF OFF OFF OFF OFF
40A OFF ON OFF OFF OFF OFF OFF OFF
*15A is the factory default setting (GFCI Cord)
DEFAULT SETTING
62
