14 JacuzziSignatureWaterHeatersJ‐S180/J‐S199
FlueInstallaon(IndoorModels)
Condensate
Trap
VercalTerminaon
(condensatecollectormustbeusedinallinstallaons)
3in(75mm)
minimum
3in(75mm)
minimum
HorizontalTerminaonusingthe
CondensateCollector
3in(75mm)
minimum
Condensate
Trap
Toadjustthecondensatecollectorposionorto
replacethefemaleventtopwithamaleventtop:
1. Loosenthe4screwsattherearbracket
2. Slidethebracketawayfromthefemaleventtop.
3. Removethe4screwsaachingthefemaleventtop
tothe
waterheater.
4. Liupthefemaleventtopandreposionasdesired
(orreplacewithamaleventtop).
5. Installthe4screwsattheventtopandghtenthe4
screwsatthebracket.
Securethefirstventcomponenttothewaterheater
withoneself‐tappingscrewattheholelocatedabove
thecondensatecollector.
Bracket
CondensateCollector
SecuringScrew
HorizontalTerminaonwithoutusingtheCondensateCollector
MaximumHeight*
5feet(1.52m)
Regionsofcoldclimatewillcreatemore
condensateintheventsystem.The
condensatecollectorshouldbeusedin
coldclimates.
Ifmorethanoneelbowisusedinthe
vercalseconthecondensatecollector
mustbeused.
*Thecondensatecollectormustbeusedin
horizontalterminaonsifavercalrisein
theventsystemexceeds5.
Ifthecondensatecollectoris notused,thedrainpipemust
becappedtopreventexhaustgasesandcondensatefrom
enteringthebuilding.Thecapissuppliedontheappliance.
WARNING
Installthevenngterminaonaccordingtothediagramsandinstruconsbelow.
