J‐C100TemperatureController
TheJ‐C100controlleristhestandardtemperaturecontrollerthatissuppliedwiththewaterheater.Onindoor
modelsitisintegratedintothefrontpanel.
Dimensions(inches):
3.5Wx4.75Hx0.75D
J‐C200SpaController
TheJ‐C200controlleriswaterresistant.Avoidsplashingthecontroller.
NOTICE
Dimensions(inches):8.0Wx4.125Hx0.875D
OperangInstrucons
PriorityIndicator
PriorityModeBuon
PowerBuon
OperaonIndicator
TemperatureDisplay
TemperatureSelecon
Bath Fill
Use caution when adjusting water temperature.
J-C200
PriorityMode
Buonand
Indicator
Temperature
Selecon
Sound
WaterVolume
PowerSave
BathFill
Operaon
Buon(Power)
InUse
Indicator
Temperature
Display
BathFillIndicator
LockingtheController
TheJ‐C100controllercanbelockedbypressingthePriorityModebuonandtheup(+)buontogetherfor5
seconds.Abeepwillsoundconfirmingthatthecontrollerislocked.Thedisplay willalternatelyshow“LOC”,the
temperatureseng,andadiagnosccodeifone
hasbeenacvated.Allofthecontrollersinthesystemare
alsolocked.TounlockthecontrollerpressthePriorityModebuonandtheup(+)buontogetherfor5
seconds.
