Jacuzzi JVS185S User Manual

Page 28 of 32 IS3206VSP3J Rev-A
10.2. Parts Listing
Ref.
No.
Part No.
Description
Qty.
1
SPX3200UNKIT
Union Connector Kit (Includes 2 Nuts, Connectors & Gaskets)
1
2
SPX3200UG
Union Gasket
1
3
SPX3200ALB
Pump Strainer Housing, 2” x 2 1/2” with Drain Plugs
1
4
SPX3200DLSDB
Strainer Cover Kit (Includes Strainer Cover, Lock Ring & O-Ring)
1
5
SPX3200S
Strainer Cover O-Ring
1
6
SPX3200M2
Strainer Basket
1
7
SPX3200Z8
Diffuser Screw
1
8
SPX4000Z1
Diffuser O-Ring
1
9
SPX3200B3
Diffuser
1
10
SPX3200Z1
Impeller Screw
1
11
SPX3021R
Impeller Ring
1
12A
SPX3210C
Impeller with Impeller Screw **JVS185S ONLY
1
12B
SPX3220C
Impeller with Impeller Screw **JVS270S ONLY
1
13A
SPX3200SA
Shaft Seal Assembly
1
13B
SPX4000SAV
Shaft Seal Assembly (Viton)
1
14
SPX3200T
Housing O-Ring
1
15
SPX3200ELB
Seal Plate
1
16
SPX3200Z211
Housing Insert/Seal Plate Spacer Kit
1
17
SPX3200Z3
Housing Bolt
1
18
SPX3200Z5
Motor Bolt
1
19
SPX4000FG
Drain Plug with O-Ring
1
20
SPX3200GA
Motor Support
1
21
SPX3200WF
Optional Riser Base aligns with Pentair® WhisperFlo® pump*)
1
22
SPX3200Q
Motor Support Adapter
1
23
SPX3200LCDDB
Digital Control Interface Assembly
1
-
SPX3400DRKIT
Wall Mount Kit
1
-
SPX3200DRCC
Comm Cable Kit
1
-
SPX3200MRBPAK5
Basket Strainer Insert, Set of 5
5
POWER END
24A
SPX3202Z1VSPE
Power End Assembly (Incl. #7-23 & Motor) **JVS185S ONLY
1
24B
SPX3206Z1VSPE
Power End Assembly (Incl. #7-23 & Motor) **JVS270S ONLY
1
* WhisperFlo is a registered trademark of Pentair Aquatic Systems, which is used herein for identification purposes only.
This is a retrofit base for existing WhisperFlo pump installations.
