ENGLISH
ROUGHING-IN REFERENCE (RECTANGULAR)
12
Jacuzzi Whirlpool Bath K272000AF 7/06
36"
42"
*72"
11-7/8"
MITO™ 6, Right Hand
10" x 4"
2"
Motor
12" H x 18" L
Service Access
Opt. Service
Access
5-3/8"
NOVA™ 5, Left Hand
*60"
21"
42"
11" x 4"
Motor
12
H x 18
L
Service Acces
Opt. Service Access
2''
8-1/2''
5-3/8''
NOVA™ 5, Right Hand
*60"
21"
42"
11" x 4"
Motor
12" H x 18" L
Service Access
Opt. Service Access
2''
8-1/2''
5-3/8''
NOVA™ 5 W/3-SIDED TILE FLANGE, Left Hand
*60"
21"
42"
11" x 4"
Motor
2''
8-1/2''
7''
12" H x 18" L
Service Access
Opt. Service Access
NOVA™ 5 W/3-SIDED TILE FLANGE, Right Hand
*60"
21"
42"
11" x 4"
Motor
2''
8-1/2''
7''
12
H x 18
L
Service Access
Opt. Service Access
NOVA™ 5 WITH INTEGRAL SKIRT, Left Hand
*60"
21"
42"
11" x 4"
9-1/4"
2''
5-1/4''
Motor
NOVA™ 5 WITH INTEGRAL SKIRT, Right Hand
*60"
21"
42"
11" x 4"
9-1/4"
2''
5-1/4''
Motor
NOVA™ 536, Left Hand
10" x 4"
Motor
12" H x 18" L
Service Access
Opt. Service Access
36"
*60"
18"
2"
9"
4-5/8"
NOVA™ 536, Right Hand
36"
*60"
2"
10" x 4"
9"
4-5/8"
Motor
12" H x 18" L
Service Access
Opt. Service Access
18"
NOVA™ 536 W/INTEGRAL SKIRT, Left Hand
36"
*60"
18"
10" x 4"
2"
9"
Motor
4-5/8"
NOVA™ 536 W/INTEGRAL SKIRT, Right Hand
36"
*60"
18"
10" x 4"
2"
9"
4-5/8"
Motor
NOVA™ 6, Left Hand
*72"
21"
2"
42"
14" x 4"
8-1/2"
Motor
12" H x 18" L
Service Access
Opt. Service Access
6-7/8"
NOVA™ 6, Right Hand
*72"
21"
2"
42"
14" x 4"
8-1/2"
6-7/8"
Motor
12" H x 18" L
Service Access
Opt. Service Access
NOVA™ 636 W/INTEGRAL SKIRT, Left Hand
*72"
36"
17-7/8"
2"
10" x 4"
9-3/8"
Motor
6-7/8"
NOVA™ 636 W/INTEGRAL SKIRT, Right Hand
*72"
36"
17-7/8"
2"
10" x 4"
9-3/8"
Motor
6-7/8"
ROUGHING-IN
*Add 1/4" (6,4 mm) to this dimension when roughing-in for 3-wall niche.
NOTE: 1. The overall dimensions are nominal with a tolerance of +0 and -1/4" (6,4 mm).
2. Service Access dimensions given are minimum. Service access is still required for units that do not have pre-installed Pump/Motor.
3. Measurements inside each unit represent cutout in floor to allow for drain/overflow.
4. All measurements are in inches. To convert to millimeters, multiply inches by 25.4.
5. Not all export units come with pre-installed Pump/Motor.
