ENGLISH
ROUGHING-IN REFERENCE (RECTANGULAR)
13
Jacuzzi Whirlpool Bath K272000AF 7/06
SIGNA™ 5, Left Hand
*60"
12"
42"
5"
4-1/4"
13" x 5"
30"
Motor
12" H x 18" L Service Access
Opt.
Service
Access
SIGNA™ 5, Right Hand
*60"
42"
5"
4-1/4"
13" x 5"
30"
Motor
12" H x 18" L Service Access
Opt.
Service
Access
12"
SIGNA™ 5 W/3-SIDED TILE FLANGE, Left Hand
12"
30"
5"
42"
*60"
13" x 5"
Motor
12" H x 18" L Service Access
Opt.
Service
Access
4-1/4"
12"
30"
5"
42"
*60"
13" x 5"
SIGNA™ 5 W/3-SIDED TILE FLANGE, Right Hand
4-1/4"
Motor
12" H x 18" L Service Access
Opt.
Service
Access
*60"
42"
6-3/4"
4-1/4"
16" x 5"
30"
(Right hand only as shown)
12-3/4"
SIGNA™ 5 W/INTEGRAL SKIRT
Motor
SIGNA™ 6, Left Hand
12-1/2"
36"
11-
1/4"
5"
42"
*72"
18-1/2" x 5"
Motor
12" H x 18" L Service Access
Opt.
Service
Access
SIGNA™ 6, Right Hand
12-1/2"
36"
11-
1/4"
5"
42"
*72"
18-1/2" x 5"
Motor
12" H x 18" L Service Access
Opt.
Service
Access
ROUGHING-IN
*Add 1/4" (6,4 mm) to this dimension when roughing-in for 3-wall niche.
NOTE: 1. The overall dimensions are nominal with a tolerance of +0 and -1/4" (6,4 mm).
2. Service Access dimensions given are minimum. Service access is still required for units that do not have pre-installed Pump/Motor.
3. Measurements inside each unit represent cutout in floor to allow for drain/overflow.
4. All measurements are in inches. To convert to millimeters, multiply inches by 25.4.
5. Not all export units come with pre-installed Pump/Motor.
