ENGLISH
ROUGHING-IN REFERENCE (OVAL)
NOTE: These units have been provided with cutout templates included in shipping carton.
See CUTOUT information for each model on page 8.
FRESCO™, Left Hand
71-1/2"
42"
35-3/4"
11-3/4"
2"
12" x 4"
Motor
12" H x 18" L
Service Access
4-1/2"
FRESCO™, Right Hand
71-1/2"
42"
11-3/4"
2"
12" x 4"
Motor
12" H x 18" L
Service Access
4-1/2"
35-3/4"
62"
21-1/2"
2"
43"
12" x 4"
9-1/2"
GALLERY™ 5 OVAL, Left Hand
5"
Motor
12" H x 18" L
Service Access
GALLERY™ 5 OVAL, Right Hand
62"
21-1/2"
2"
43"
12" x 4"
9-1/2"
5"
Motor
12" H x 18" L
Service Access
72"
21"
42"
2"
14" x 4"
11-1/2"
GALLERY™ 6, Left Hand
Motor
12" H x 18" L
Service Access
6-7/8"
GALLERY™ 6, Right Hand
72"
21"
42"
2"
14" x 4"
11-1/2"
Motor
12" H x 18" L
Service Access
6-7/8"
21"
12-1/2"
2"
14" x 4"
72"
42"
GALLERY 6 UNDERMOUNT, Left Hand
Motor
12" H x 18" L Service Acces
s
GALLERY 6 UNDERMOUNT, Right Hand
21"
12-1/2"
2"
14" x 4"
72"
42"
Motor
12" H x 18" L Service Acces
s
42
"
72"
13" X 6"
3"
36"
11"
(Right-hand only)
LUNA™
Motor
12" H x 18" L
Service Acces
s
MILANO™, Left Hand
20"
2"
11"
71-1/2"
40"
12" x 4"
5"
Motor
12" H x 18" L Service Access
MILANO™, Right Hand
20"
2"
11"
71-1/2"
40"
12" x 4"
5"
Motor
12" H x 18" L Service Access
14
Jacuzzi Whirlpool Bath K272000AF 7/06
ROUGHING-IN
NOTE: 1. The overall dimensions are nominal with a tolerance of +0 and -1/4" (6,4 mm).
2. Service Access dimensions given are minimum. Service access is still required for units that do not have pre-installed Pump/Motor.
3. Measurements inside each unit represent cutout in floor to allow for drain/overflow.
4. All measurements are in inches. To convert to millimeters, multiply inches by 25.4.
5. Not all export units come with pre-installed Pump/Motor.
