ENGLISH
ROUGHING-IN REFERENCE (OVAL)
NOTE: These units have been provided with cutout templates included in shipping carton.
See CUTOUT information for each model on page 8.
15
Jacuzzi Whirlpool Bath K272000AF 7/06
OPALIA™, Left Hand
4"
36"
44"
32"
12"
3"
72"
13" X 4"
Motor
12" H x 18" L
Service Access
4-11/16"
OPALIA™, Right Hand
4"
36"
44"
32"
12"
3"
72"
13" X 4"
4-11/16"
Motor
12" H x 18" L
Service Access
62"
21-1/2"
2"
43"
12" x 4"
9-1/2"
RIVA™ 5, Left Hand
5"
Motor
12" H x 18" L
Service Access
72"
21"
42"
2"
14" x 4"
11-1/2"
RIVA™ 6, Left Hand
Motor
12" H x 18" L
Service Access
6-7/8"
RIVA™ 6, Right Hand
72"
21"
42"
2"
14" x 4"
11-1/2"
6-7/8"
Motor
12" H x 18" L
Service Access
ROUGHING-IN
62"
21-1/2"
2"
43"
12" x 4"
9-1/2"
RIVA™ 5, Right Hand
5"
Motor
12" H x 18" L
Service Access
NOTE: 1. The overall dimensions are nominal with a tolerance of +0 and -1/4" (6,4 mm).
2. Service Access dimensions given are minimum. Service access is still required for units that do not have pre-installed Pump/Motor.
3. Measurements inside each unit represent cutout in floor to allow for drain/overflow.
4. All measurements are in inches. To convert to millimeters, multiply inches by 25.4.
5. Not all export units come with pre-installed Pump/Motor.
