10
CALL NOW 800.798.1779
SANCTUARY 1
www.infraredsauna.com
Assembly Instructions Cont’d
Follow the connections as in the following illustration:
1. Connect the black and white cable coming out of the back of the under bench support to one of the left side
wall connectors.
2. Connect the side black and white wall cable to one of the floor connectors.
3. Connect the black and white back wall cable to the other floor connector.
4. Connect the green ground connectors together.
5. The two remaining cables labeled “VRT” will be connected if Vibrational Resonance Therapy is being added to
the sauna. If you did not add this to your sauna, these cables will not be used.
6 - CONNECT HEATER CONNECTION UNDER BENCH
You can plug any male connector to any female one as long as the colors match.
To Next Page
