SANCTUARY Y
Assembly Instructions Cont’d
1. The Sanctuary Y - FS comes with two benches. The benches are identical. Please located the pieces for one
bench as shown below:
(4 x)
(4 x legs, 2 x long side supports, 2 x short side supports)
9 - ASSEMBLING BENCHES
1. The side walls must be secured to the back wall and wood roof piece using the attached eye hooks.
2. Screw in one of the eye hooks between the left side wall and backwall and one between the right side wall and
backwall.
3. Secure one of the eye hooks between the left side wall and top front of the wood roof piece and one between
the right side wall and the top front of the wood roof piece.
8 - INSTALLING WALL LOCKS
THIS STEP IS VERY IMPORTANT.
PLEASE DO NOT OMIT THIS STEP.
Attach the eye hook so that it is screwed
into side walls and the wood roof piece.
Attach eye hook so that it is screwed
into both the side walls and back walls.
To Next Page
