Jade Built-In Refrigerators - Page 14

INSTALLATION GUIDE – FRAMED MODEL PANELS
Backer Panel Thickness
1
/4" (0.64 cm)
Spacer Panel Thickness 0.100" (0.25 cm)
If Raised Panel is Used Overall Front Panel
Thickness Not to Exceed 1
1
/4" (3.18 cm)
NOTES:
1. Use countersink screws for attaching the
backer panel to the front panel.
2. On 42" custom panels, watch location of
handle mounting due to undercut of front
panel.
3. For freezer dispenser front panels, remove
fountain trim and tape it to the backside
of the backer panel. Note: Recycle symbol
should be visible and located at the bottom.
4. You may want to remove any additional
material on the backer panel when used in
conjunction with a front panel. Remove
1
/32"
of thickness and
1
/2" of width on the inside
surface of the backer panel. This will help
ease assembly of the panel assembly onto
the door.
42"-Wide Cabinet 48"-Wide Cabinet
BACKER PANEL in. cm in. cm
(A) Grille Panel
W Width 40
1
/4 102.24 46
1
/4 117.48
H Height 8
3
/4 22.23 8
3
/4 22.23
(B) Freezer Dispenser Panel
W Width 15
1
/16 38.26 17
5
/16 43.97
W1 Width 2 5.08 2 5.08
W2 Width 14
1
/2 36.83 14
1
/2 36.83
H Height 69
1
/8 175.58 69
1
/8 175.58
H1 Height 34
1
/16 86.52 34
1
/16 86.52
H2 Height 48
1
/8 122.24 48
1
/8 122.24
(C) Freezer Nondispenser Panel
W Width 15
1
/16 38.26 17
5
/16 43.97
H Height 69
1
/8 175.58 69
1
/8 175.58
(D) Refrigerator Panel
W Width 22
5
/16 56.67 26
1
/16 66.20
H Height 69
1
/8 175.58 69
1
/8 175.58
SPACER PANEL in. cm in. cm
(A) Grille Panel
W Width 39
1
/4 99.7 45
1
/4 114.94
H Height 7
3
/4 19.69 7
3
/4 19.69
(B) Freezer Dispenser Panel
W Width 14
1
/16 35.72 16
5
/16 41.43
W1 Width 2 5.08 2 5.08
W2 Width 14
1
/2 36.83 14
1
/2 36.83
H Height 68
1
/8 173.04 68
1
/8 173.04
H1 Height 34
1
/16 86.52 34
1
/16 86.52
H2 Height 48
1
/8 122.24 48
1
/8 122.24
(C) Freezer Nondispenser Panel
W Width 14
1
/16 35.98 16
5
/16 41.43
H Height 68
1
/8 173.04 68
1
/8 173.04
(D) Refrigerator Panel
W Width 21
5
/16 54.13 25
1
/16 63.66
H Height 68
1
/8 173.04 68
1
/8 173.04
FRONT DECORATOR PANEL in. cm in. cm
(A) Grille Panel
W Width 40
1
/4 102.24 46
1
/4 117.48
H Height 8
3
/4 22.23 8
3
/4 22.23
(B) Freezer Dispenser Panel
W Width 14
7
/8 37.78 17
1
/8 43.50
W1 Width 2
1
/4 5.72 2
1
/4 5.72
W2 Width 14
1
/4 36.20 14
1
/4 36.20
H Height 69
1
/4 175.90 69
1
/4 175.90
H1 Height 34
5
/16 87.15 34
5
/16 87.15
H2 Height 47
13
/
16
121.44 47
13
/16 121.44
(C) Freezer Nondispenser Panel
W Width 14 7/8 37.78 17
1
/8 43.50
H Height 69 1/4 175.90 69
1
/4 175.90
(D) Refrigerator Panel
W Width 22 1/8 56.20 26
7
/8 68.26
H Height 69 1/4 175.90 69
1
/4 175.90
12
