Jancy Engineering 17982 - Arbor and Coolant Assembly Breakdown

machine parts list
12
item description part # qty
300 CHIP GUARD ASSEMBLY 07026 1
301 GUIDE PLATE 07213 1
302 FLANGE PLATE 07214 1
303 SCR,FHSCS M6 X 12 054140 1
304 SFHMS, M6 X 20 05MT404 1
306 SHCS, M6 X 12 0070535 1
307 WASHER, SPLIT M6 07016 1
308 NUT, M6 070308 1
611 BOTTLE ASSEMBLY 0151511 1
614 SHCS, M4 X 12 06770 2
810 KNOCK-OUT WEDGE 07517 1
900 ARBOR ASSEMBLY 07504 1
901 ARBOR BODY 07505 1
item description part # qty
902 PLUNGER 07530 1
903 SPRING 07507 1
904.1 COOLANT INDUCER 07508 1
904.2 HOSE CONNECTION 07529 1
904.3 INDUCER PIN 07510 1
904.5 SEAL 07511 2
905 WASHER 07512 2
906 SPACER 07513 1
907 WASHER 07533 1
908 SSS, M10 X 10 07336 2
909 RETAINING RING, INTERNAL 19W 0215067 1
910 RETAINING RING, EXTERNAL 32Z 07215 1
911 STOP ROD, M6 07216 1
912 RUBBER WASHER 07531 1
REV. B
11
6
003
3
03
103
7
0
3
6
03
8
0
3
2
03
018
119
1
0
.
0
09
20.
0
0
9
50.0
0
9
7
0.
0
09
80
.
00
9
9
0
.0
09
4
03
3
0
.
0
0
9
0
1.
0
09
4
0.0
0
9
60.009
50.00
9
4
1
6
904.2
910
906
905
904.5
904.1
904.5
905
901
902
912
907
909
908
903
904.3
Rev. C
