14
motor parts list
item description part # qty
1 RETAINING RING, INTERNAL 55W 07128 1
8 SPINDLE 07129MT2 1
9 KEY, SQUARE 6 X 6 X 15 07127 1
10 BEARING, 6006 07126 1
11 RETAINING RING, EXTERNAL 30Z 07125 1
12 SEAL, SPINDLE 28 X 47 X 7 07518 1
14 BEARING, 6005 07122 1
15 GEAR CASE 07259 1
18 SHCS, M5 X 30 03097 4
19 WASHER, SPLIT M5 07023 4
20 SHIFT FORK 07146 1
21 SHIFT PIN 07145 1
23 SHIFT LEVER 045014 1
24 SPRING 04591 1
25 SHIFT COLLAR 04524 1
26 WASHER, INTERNAL M5 04563 1
27 SHCS, M5 X 35 04572 1
28 TAG, SHIFT 04514 1
29 CRPHMS, M3 X 5 045793 2
30 BEARING, NEEDLE RHNA 081210 07151 2
31 WASHER, THRUST 8, 1 07158 1
32 GEARSHAFT, 12T/20T 07157 1
33 KEY, WOODRUFF 3 X 3.7 07156 1
34 GEAR, HELICAL 46T 07155 1
35 BEARING, 608 04544 1
36 BEARING, NEEDLE RHNA 101610 07147 1
37 WASHER, THRUST 10, 1 07148 1
38 GEARSHAFT, 12T 07149 1
39 KEY, SQUARE 3 X 3 X 36 07161 1
40 GEAR, DUAL 52T/44T 07150 1
41 RETAINING RING, EXTERNAL 25Z 07152 2
42 GEAR, 52T 07162 1
45 PIN, DOWEL 4 X 16 07160 1
46 O-RING 07153 1
47 COVER, GEAR CASE 07154 1
48 SFHMS, M4X16 07116 4
49 COVER, FIELD CASE 07115 1
50 CRPHMS, M4 X 8 04820 4
51 COVER, CORD 07120 1
52 PLATE, CORD 07119 1
53 SNAP BUSHING, LA6 07441 1
54 LINER, COVER 07118 1
55 SSS, M6 X 12 0070526 2
57 BRUSH SET 04550 2
58 BRUSH HOLDER 04551 2
59 TAG, MOTOR 120V 07027 1
TAG, MOTOR 240V 07028 1
60 DRIVE SCREW, #2 X 3/16 0070028 2
61 FIELD CASE 07113 1
62 WASHER, SPRING 04560 1
63 INSULATOR, FIELD 05010 1
64 INSULATOR, FIELD SCREW 04557 4
65 FIELD 120V 06580 1
FIELD 240V 06584 1
66 WASHER, INTERNAL M4 04576 2
67 SHCS, M4 X 50 07106 2
68 SHROUD 07105 1
69 ARMATURE 120V 04644 1
ARMATURE 240V 04645 1
71 BEARING, 6002 07101 1
REV. C
