18
Pch (Patch Number)
Patch numbers range from 1 to 3. The Patch number shown is
active so care should be taken in changing the Patch number while
the console is in use.
Ch (Channel)
Sets the console Channel number to be patched. Only one channel
can be displayed at a time.
Dim (Dimmer)
Sets a dimmer number to patch to the Channel shown in CH.
At (At Level)
Sets the level of the dimmer set in the DIM field. At can be set
from 0 to FF (full).
The Default Patch
The default patch on the ESP II is Patch 1, it is a one-to-one patch. That
is Channel 1 connect to Dimmer 1, Channel 2 connect to Dimmer 2, and
so on. Dimmer numbers above the number of console channels are not
connected.
Patching Dimmers to Channels
A dimmer can only be patched to one channel at a time.
Storing Changes made in Patch
When all changes to a patch have been made, press the Record button to
save these changes and leave the Patch menu. If you press the Exit key
you are prompted to either save the changes by pressing the ON(+)
button or to abandon them by pressing the OFF (-) key.
Setup Patch
To Next Page
