23
Setup Util
Menu Fields
Settings
Setup P1/2 dbo Video GMast
Util Normal Momt Mono Hold more
The Setup Utilities Menu
Preset 2 Master Fader Operation
The SETUP UTIL (Utility) menu is used to configure various ESP II
controls to suit your preffered operating method. To open the Util menu,
press the SETUP button, move the cursor to the UTIL field and press the
ON (+) key, the menu consists of four fields as follows:
P1/2
Many operators who use the Preset faders while running a show prefer to
move the 2 Preset Master faders together, with one hand, to crossfade
between Presets. To allow this on an ESP II the Preset 2 Master fader
can be reversed such that at the top of its travel output from Preset 2 is
zero (0) and at the bottom of its travel the output is 100%.
To change the P1/2 field to REV (Reverse) move the cursor to the P1/2
field and press the Plus (+) button. Pressing the Plus (+) button again will
toggle between NORM (Normal) and REV (Reverse)
D.B.O. (Dead Black Out)
The DBO button can be set to either momentary or latching operation. To
alter DBO operation move the cursor over the DBO field and press either
the On (+) or Off (-) key. The possible settings are:
Momt
Momentary operation, the console is Blacked Out only while the DBO
button is held depressed.
Ltch
Latching, the console is Blacked Out by pressing the DBO button.
Output is restored when the DBO button is pressed again.
DBO Type
VDU Type Master Type
To Next Page
