Getting Started
Connecting Power
Plug the socket end of the power cord into the IEC power receptacle
located on the rear face of the ESP II. The other end of the power cord
should be plugged into a 3 pin grounded outlet. It is important that the
ESP II is electrically grounded, if in doubt about whether or not an outlet
is grounded contact a licensed electrician.
Connecting the Output to a dimmer
ESP II provides two methods of connection to dimmer systems. The
DMX output is standard on all consoles. Optional Socapex output panels
can be simply fitted to the console to provide 0 - 10v wire-per-channel
outputs.
• DMX-512 Output
Connect from the consoles DMX output to the DMX input on the
dimmer rack, check the dimmer instruction manual for details on
selecting DMX Channels and looping the DMX line to other dimmer
racks.
Up to 512 dimmer channels can be controlled in this way.
• Analogue Outputs (Optional)
Connect from the consoles Socapex outputs to the dimmer rack input
Up to 8 Socapex connectors can be fitted to a console to provide up
to 240 dimmer channels
Connecting Desklights
Desklights are available as an optional accessory. Only Littlelite or
compatible desklights with 3 pin Cannon type connectors should be used.
