20
Setup Desk
Master
When the MASTER field is set ON the MIDI IN socket can be used to
receive channel level information from the DMX output of a second ESP
II console. To use an ESP II as a Master console it must be set to WIDE
mode. If MASTER is turned on without WIDE being on a message will
be displayed offering the option of reseting the desk to WIDE but this
will clear the data already recorded.
When MASTER is turned ON the ESP II checks to see what extra chan-
nels are available (on the Slave console) and displays a message confirm-
ing the number of extra channels.
Slave
When the SLAVE field is set ON the DMX socket is used to send chan-
nel level information to the MIDI intput of a second ESP II console.
When a console is in Slave mode only the Preset faders and Flash buttons
are active.
Lamp (DeskLight)
The intensity of the Desklight(s) can be adjusted by setting the LAMP
field from 0 (0%) to FF (100%)
To set the Desklight level press SETUP move the cursor to the DESK
field; press the Plus (+) button move the cursor to the LAMP field and
enter a value between 0 and FF (Full) using the + and - buttons.
Wide
One of the most powerful features of the ESP II is its ability to work as a
single preset board outputing double the number of channels normally
available. In applications where Colour Scrollers or Moving Lights are
being controlled this feature greatly extends the usefullness of the con-
sole. An ESP II 24, for instance could control 48 colour scrollers.
WIDE should be turned on before recording. Once a console has been set
to WIDE the Preset 2 faders are used to control the higher numbered
channels. For example on an ESP 48 the Preset 2 faders would control
channels 49 to 96. The Preset 2 Master Fader is disabled.
Psets
The PSETS field is used to alter the operation of the bottom Preset faders
so that they can either be used as extra Preset 1 faders to control Wide
mode channels or as a regular second preset.
Setting the console to WIDE automatically switchs the Preset 2 faders to
