49
To link two ESP II consoles together connect a cable, wired as detailed below between the
DMX output of the desk to be the slave to the MIDI input on the desk to be used as
Master.
Cannon 5 Pin Din 5 Pin
PIN No PIN No
2 390R 1/4w 5% 4
45
Requirements90 volts to 265 volts AC, 50-60 Hz
Consumption 40 watts (85 watts with analog outputs)
Connector IEC 3-pin inc. fuse, switch and mains filter
Fuse 2 amp M205
Desk Link Cable
Power
Midi Note Messages
Midi Note messages run from 0 to 127.
Midi Note Midi Note Midi Note Midi Note Midi Note Midi Note
36 C1 48 C2 60 C3 72 C4 84 C5 96 C6
37 C#1 49 C#2 61 C#3 73 C#4 85 C#5 97 C#6
38 D1 50 D2 62 D3 74 D4 86 D5 98 D6
39 D#1 51 D#2 63 D#3 75 D#4 87 D#5 99 D#6
40 E1 52 E2 64 E3 76 E4 88 E5 100 E6
41 F1 53 F2 65 F3 77 F4 89 F5 101 F6
42 F#1 54 F#2 66 F#3 78 F#4 90 F#5 102 F#6
43 G1 55 G2 67 G3 79 G4 91 G5 103 G6
44 G#1 56 G#2 68 G#3 80 G#4 92 G#5 104 G#6
45 A1 57 A2 69 A3 81 A4 93 A5 105 A6
46 A#1 58 A#2 70 A#3 82 A#4 94 A#5 106 A#6
47 B1 59 B2 71 B3 83 B4 95 B5 107 B6
