8
Description of Major Parts
K P1 and P2 Masters
These 2 faders scale the level of the top (P1) and bottom (P2) presets.
L Flash Master Controls
The Flash Master fader scales the level of the flash buttons. The Add
/ Solo switch above this fader sets the method of operation for the
flash buttons.
M Grand Master
Scales the level of all outputs (except the flash buttons).
K Power Input
Consists of an IEC power input complete with fuse and on/off switch.
L Desklight Outlets
Designed for use with Littelite or compatible desklamps
M DMX Output
Control output for connection to dimmer systems or interfaces using
DMX-512 protocol
N Midi
Control input allowing Midi signals to control various functions of
the console.
