J&W JW-A780LM-D2 User Manual

- 15 -
AMD Series User's Manual
JHPD
SF
AN
1
FUSB1
FUSB2
PS 2
USB1
DIMM 1
DIMM 2
JRS790M2C0 2_DV 1 0
184*234
.
HDMI
CF
AN
JKB
B T1
AUD IO
JCOM
SFAN2
AT
XPW
R
SPEA K
FDD
JHPD
SF
AN
1
FUSB1
FUSB2
PS 2
USB1
DIMM 1
DIMM 2
JRS790M2C0 2_DV 1 0
184*234
.
HDMI
CFAN
JKB
B T1
AUD IO
JCOM
SFAN2
ATXPW
R
SPEA K
FDD
Pin Pin Assignment Pin Pin Assignment
1 VCC 2 VCC
3 Data 0- 4 Data 0-
5 Data 0+ 6 Data 0+
7 Ground 8 Ground
9 No Pin 10 NC
3.5 Additional USB Port Headers
3.6 Front Panel Audio Header
Pin No. Header HD Audio Denition AC97 Audio Denition
1 PORT1L Microphone_Left Microphone
2 AGND Ground Ground
3 PORT1R Microphone_Right MIC Power
4 PRESENCE# -ACZ_DET N/A
5 PORT2R Line2_Right Line out (R)
6 SENSE1_RETURN AuD_R_Return N/A
7 SENSE_SEND FAUDIO_JD N/A
8 No Pin N/A N/A
9 PORT2L Line2_Left Line Out(L)
10 SENSE2_RETURN AuD_L_Return N/A
