J&W JW-A780LM-D2 User Manual

- 4 -
AMD Series User's Manual
1.2 Specications
JW-A780LM-D2 V3.0
CPU
- Support AMD(R) Socket AM3/AM2+/AM2 processors
- AMD Phenom™ II x4/ Phenom™ II x3/ Phenom™ II x2/ Athlon™ II x4/ Athlon™
II x3/Athlon™ II x2/ Athlon™ 64 X2 / Athlon™ 64 / Sempron™ processors
- Support AMD Cool'n'Quiet!™ Technology
- HyperTransport™ 3.0/1.0, 5200/2000 MT/s
-
Support 95W TDP Processors Max.
Main Chipset - AMD 760G +SB710
Integrated Graphics - Radeon HD 3000
Main Memory
- Dual Channel DDR2 1066/800/667 MHZ support
- Max capacity: 4GB DDR2
- DIMM slots: 2 x DDR2
BIOS
- AMI BIOS
- CPU temperature, Fan speed, System Voltage monitoring
Rear Panel I/O
- 1 x PS/2 Keyboard port
- 1 x PS/2 Mouse port
- 1 x HDMI port
- 1 x DVI port
- 1 x VGA port
- 1 x RJ45 port
- 4 x USB 2.0 ports, USB 1.1 is compliant
- 3 x Audio ports (Line In / Line Out / MIC In)
Internal I/O
Connectors
- 1 x 24-pin ATX main power connector
- 1 x 4-pin ATX 12V power connector
- 1 x Floppy disk drive connector
- 1 x IDE connector
- 4 x SATA 3Gb/s connectors (supporting RAID 0,1,10
，
JBOD)
- 1 x CPU fan header
- 2 x System fan headers
- 1 x Front panel header
- 1 x Front panel audio header
- 1 x S/PDIF Out header
- 1 x COM port header
- 2 x USB 2.0 headers for additional 4 USB 2.0 ports (by cables)
- 1 x buzzer header
Sound
- Onboard 6-channel
- Front Panel Jumper, provides stereo MIC port on front panel
Onboard LAN - Onboard 10/100/1000Mbps compatible LAN (Optional)
Expansion Slots
- 1 x PCI Express x16 slot (PCI Express 2.0)
- 1 x PCI slot
- Support PCI Bus interface v2.3 compliant
Form Factor - Micro ATX (185mm*235mm)
