J&W JW-A780LM-D2 User Manual

- 25 -
AMD Series User's Manual
►
Onboard Device Conguration
Click <Enter> key to enter its submenu.
BIOS SETUP UTILITY
Advanced
Onboard Devices Configuration Disabled:disablea the
intergrate IDE Controller
PRIMARY:enables only the
Primary IDE Controller.
SECONDARY:enables ony the
Secondary IDE Controller.
BOTH:enables both IDE
Controllers
←
Select Screen
↑↓
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Onboard PCI IDE Cintroller
Hard Disk Write Protect
IDE Detect Time Out(Set)
ATA(PI) 80Pin Cable Detection
Onboard Floppy Controller
Serial Port1 Address
Serial Port2 Address
Parallel Port Address
Lan Controller
Onboard 8056 Lan Boot ROM
Onboard 8040 Lan Boot ROM
Onboard 8111DL Lan Boot Rom
Onboard 8102E Lan Boot Rom
[Both]
[Disabled]
[35]
[Host & Device]
[Enabled]
[3F8/IRQ4]
[Disabled]
[Disabled]
[Enabled]
[Disabled]
[Disabled]
[Disabled]
[Disabled]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
These options allow you to Enabled/Disabled for Floppy Controller, onboard LAN
Control set the addresses for Serial Port1& Port2.
• Onboard PCI IDE Controller
This option allows you to Select PCI IDE training mode
• Hard disk write protect
Disable/enable device write protection.this will be efctive only if device is accessed through
BIOS
• IDE Detect Time Out
Select the time out value for detecting ATA/ATAPI device(s)
• ATA(PI) 80Pin Cable Detection
Select the mechanism for detecting 88pin ATA(PI) Cable.
• Onboard Floppy Controller
Allows BIOS to Enable or Disable FLOPPY Controller
• Serial Port1 Address
Allows BIOS to Select Serial Port1 base Addresses.
• Serial Port2 Address
Allows BIOS to Select Serial Port2 base Addresses.
• Parallel Port Address
Allows BIOS to Parallel Port base Addresses.
• Lan Controller
Enable:turn on the lan Disabled:shut the lan
• Onboard 8056 Lan Boot ROM
Available options:Disabled, Enabled
• Onboard 8040 Lan Boot ROM
Available options:Disabled, Enabled
• Onboard 8111DL Lan Boot ROM
Available options:Disabled, Enabled
• Onboard 8102E Lan Boot ROM
Available options:Disabled, Enabled
