BIOS SETUP UTILITY
JUSTw00T!
Memory Configuration Enable Bank Memory
Interleaving
←
Select Screen
↑↓
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Bank Interleavin
Channel Interleaving
Enable Clock to All DIMMs
MemClk Tristate C3/ATLVID
Memory Hole Remapping
DCT Unganged Mode
Power Down Enable
Power Down Mode
[Auto]
[XOR of Address
bit]
[Disabled]
[Enabled]
[Always]
[Enabled]
[Channel]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
• Bank Interleaving
Sets the bank interleaving feature.
• Enable Clock to All DIMMs
This item is to enable or disable the unused clocks to DIMMs even the memory slots are not
populated.
• MemClk Tristate C3/ATLVID
Enables or disables the MemClk Tri-Stating during C3 and Alt VID.
• Memory Hole Remapping
Enables or disables the memory remapping around the memory hole.
• DCT Unganged Mode
This item allows the selection of the unganged DRAM mode (64-bit width).
• Power Down Enable
This item is to enable or disable the DDR power down mode.
• Power Down Mode
Available options: Channel
，
Chip Select
・
Press <Esc> key to return to "JUSTw00T!" menu.
• Dimm Voltage Control
This item allows you to adjust the DRAM Voltage.
• Dram Voltage
This eld displays the current voltage of DRAM.
• CPU Voltage Control
This item allows you to adjust the CPU Voltage.
• Vcore
This eld displays the current voltage of CPU.
• K10 CPUNB Voltage Control
Control K10 CPUNB Working Voltage.
• NB Voltage Control
This item allows you to adjust the NB Voltage.
• NB Voltage
This eld displays the current voltage of NB.
• SB Voltage Control
This item allows you to adjust the SB Voltage.
• SB Voltage
This eld displays the current voltage of SB.
• HT Voltage Control
This item allows you to adjust the HT Voltage.
• BIOS Number Select
Single BIOS and double BIOS switch
.
• Onboard Lan Select
Option:ATX,MATX
