J&W JW-H61M-D3 User Manual

- 26 -
JW-H61M-D3 User's Manual
Aptio Setup Utility - Copyright (C) 2010 American Megatrends,Inc.
Chipset
Intel ME Subsystem Configuration
ME Version
ME Subsystem
ME Temporary Disable
End of Post Message
7.0.4.1197
[Enabled]
[Diablsed]
[Enabled]
ME Subsystem Help
→ ←
: Select Scree
↑↓
:
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F7: Previous Values
F8: Fail-Safe Values
F9: Optimized Defaults
F10: Save & Exit
ESC: Exit
Version 2.02.1205. (C)Copyright 2010 American Megatrends, Inc.
►
ME Subsystem
Click <Enter> key to enter its submenu.
• ME Subsystem
Available options: Disabled
，
Enabled
• ME Temporary Disable
Available options: Disabled
，
Enabled
• End of Post Message
Available options: Disabled
，
Enabled
・
Press <Esc> key to return to "Chipset" menu.
►
ME Subsystem
Click <Enter> key to enter its submenu.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends,Inc.
Chipset
Serial Port Control
Super IO Chip
►
Serial Port 0 Configuration
NCT5577D
Set Parameters of Serial
Port 0 (COMA)
→ ←
: Select Scree
...
ESC: Exit
Version 2.02.1205. (C)Copyright 2010 American Megatrends, Inc.
►
Serial Port 0 Confguration
Click <Enter> key to enter its submenu.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends,Inc.
Chipset
Serial Port 0 Configuration
Serial Port
Device Settings
Change Settings
[Enabled]
IO=3F8h; IRQ=4;
[Auto]
Enable or Disable Serial
Port (COM)
→ ←
: Select Scree
...
ESC: Exit
Version 2.02.1205. (C)Copyright 2010 American Megatrends, Inc.
• Serial Port
Enable or Disable Serial Port (COM).
• Change Settings
Select an optimal setting for Super IO device.
