Jandy AquaLink RS PDA User Manual

Page 20
Section 4. System Startup
4.1 HandheldRemoteProgramming
4.1.1. Basic Programming Menu
To set a particular piece of equipment to turn on
and off at predetermined times, highlight MENU
and press SELECT (see Figure 23). Highlight
PROGRAM and press SELECT. Use the UP or
DOWN buttons to highlight the equipment (for
example, Filter Pump) then press SELECT. Follow
the on-screen prompts. Use the UP or DOWN
buttons to pick each number, starting with ON
hours, press SELECT to enter and move on to the
next item to change, including picking what day(s)
the program will run. If you make a mistake, use
theBACKbuttontoreturntoanumber.Ifthe
program is already entered, highlight CHANGE
PROGRAM and step through to the entry that
should be corrected.
3. Use the UP and DOWN buttons to highlight
the desired RF channel. Then press
SELECT.
4. When the RF channel is selected, the
following message appears on the PDA
display screen:
SetslideswitchonJ-BoxPCBtothe
LEARNMODE.
5. At the PCB in the Transceiver J-box, slide
the Learn Switch to LEARN (ON). See
Figure 22.
SET RF CHANNEL
RF CHANNEL: 1
Use ARROW KEYS
to set the
RF CHANNEL.
Press SELECT to
continue.
P
o
o
l
D
i
g
i
t
a
l
A
s
s
i
s
t
a
n
t
1 2
select
back
PDA
UP
Button
DOWN
Button
SELECT Button
Figure 21. PDA Handheld Remote Channel Setup
and Buttons
P
o
o
l
D
i
g
i
t
a
l
A
s
s
i
s
t
a
n
t
1 2
select
back
PDA
AIR POOL
78°
80°
POOL MODE
POOL HEATER
SPA MODE
SPA HEATER
MENU
EQUIPMENT ON/OFF
ON
ON
OFF
OFF
FRI 10:30 PM
Figure 23. PDA Handheld Remote Buttons
BACK
Button
UP
Button
DOWN
Button
SELECT
Button
HOT KEY 1
HOT KEY 2
Power ON/OFF
Button
6. On the PDA Handheld Remote display
screen, a prompt will appear with
instructions to slide the J-box Learn Switch
out of LEARN (OFF) and to press the J-box
Reset Switch.
7. At the PCB in the Transceiver J-box, slide
the Learn Switch out of LEARN and press
the Reset Switch. The Red and Green LEDs
on the J-box will blink simultaneously (see
Figure 22).
Figure 22. Tranceiver J-box PCB Learn Switch
MAIN CONNECTOR
RESET
D2
D3
LEARN
Y B RG
OFF ON
LEARN
OFF ON
Transceiver
PCB
Reset Switch
Learn
Switch
Shown
in Learn
Mode
- Switch
Position
On.
Green
LED
Red
LED
