Page 5
Jandy
®
JXi
™
Gas-Fired Pool and Spa Heater | Installation & Operation Manual
1.3 Warranty
The Jandy JXi heater is sold with a limited factory
warranty.
Make all warranty claims to your Jandy dealer or
directly to Jandy. Claims must include the heater
serial number and model (this information can be
found on the rating plate), installation date, and
name of the installer. Shipping costs are not included
in the warranty coverage.
The warranty does not cover damage caused
by improper assembly, installation, operation,
winterizing, field modification, or failure to earth bond
and properly ground the unit. Also, damage to the
heat exchanger by corrosive water is NOT covered
by the warranty.
1.4 Technical Assistance
Consult the Jandy technical support department or
your local Jandy dealer with any questions or problems
involving your Jandy equipment. An experienced
technical support staff is ready to assist you in
assuring the proper performance and application of
Jandy products. For technical support call the Jandy
technical support department at (800) 822-7933.
1.5 Specifications
Supply Gas
INSTALLATION LOCATION*
NATURAL GAS (NG) CERTIFIED INDOOR (US ONLY), OUTDOOR / COVERED SHELTER
LIQUID PROPANE (LP) OUTDOOR / COVERED SHELTER
OUTDOOR OPERATION AMBIENT
AIR
ANY OUTDOOR OPERATION IN AMBIENT AIR UP TO 40°F (4°C)
GAS PIPE HEATER GAS VALVE
CONNECTION
†
NATURAL GAS (NG)
3/4 in NPT
LIQUID PROPANE (LP)
Inlet Gas supply Pressure
‡
Min
NATURAL GAS (NG)
4.0 in WC
LIQUID PROPANE (LP)
Water Pipe/Heater Connection
NATURAL GAS (NG)
• PVC/CPVC 2 in unthreaded
• Jandy threaded union
LIQUID PROPANE (LP)
Water Flow Rate
Min
NATURAL GAS (NG)
30 gpm
(76 lpm)
LIQUID PROPANE (LP)
Working Water Pressure
NATURAL GAS (NG)
2 psi**
LIQUID PROPANE (LP)
Exhaust Vent Connection Size (Cate-
gory I)§ See Section 3.3.4
NATURAL GAS (NG)
• Model 200: 6 in
• Model 260: 7 in
• Model 400: 8 in
LIQUID PROPANE (LP)
Exhaust Vent Connection Size (Cate-
gory III)§ See Section 3.3.4
NATURAL GAS (NG)
• All Models: 4 in
LIQUID PROPANE (LP)
Electrical Supply
NATURAL GAS (NG)
• 120 VAC@<5amps
• 240 VAC@<2.5amps
LIQUID PROPANE (LP)
High Altitude
NATURAL GAS (NG)
Appliances are normally derated when installed at high elevation. This is
not necessary with the JXi heater because it has a special venturi-type
combustion system which self-compensates for changes in barometric
pressure. Air flow through the blower inlet pulls the correct flow of gas into
the burner regardless of air density.
JXi heaters are CSA certified for elevations of up to 4,500 feet above sea
level. At elevations above 4,500 ft., the heater BTU output can be expected
to be reduced by 4% for every 1,000 feet over 4,500 feet above sea level.
LIQUID PROPANE (LP)
* Indoor installation is not recommended for liquid propane heaters.
**Adjustable water pressure switch factory set to 7 psi.
See section 5.3 for adjustment instructions.
Review Special Precautions for liquid propane heaters (Section 4.3)
Any changes to the heater, gas controls, gas valve, air orifice, gas orifices, wiring, or
improper installation may void the warranty. If change is required to any of the above;
contact your local Jandy distributor, visit www.jandy.com or call technical support at
800.822.7933.
†For gas pipe size requirements see Section 4
‡Value displayed is for operating (fired) pressure not static.
§ Use type B double-wall gas vent, per table 13.1(a) NFPA 54
