Page 46
contact with the pin on the power distribution board
that is labeled "L2" where the red wire is connected
(test point N). No voltage at this point means that the
power distribution circuit board has shorted and needs
to be replaced. If the voltage is correct, move the red
lead to the connection at the igniter wire quick discon-
nect (test point H). No voltage means that the wire
between the power distribution board and the igniter
test point H is faulty. Check the connections or replace
the power distribution board. Place the red lead of the
meter in contact with the pin on the power distribution
board that is labeled "IGN" where the red wire is
connected (test point P). The meter should show 98-
126 Volts when the control is not energizing the
igniter or zero volts when the control is energizing the
igniter. If it does not, then the power distribution circuit
board is shorted or open. Replace this component. If
the correct voltage is measured at this point, move the
red meter lead to the igniter wire quick disconnect
(test point I). No voltage here during the trial for
ignition means that the wire between the power
distribution board and the igniter test point I is faulty.
Check the connections or replace the power distribu-
tion board.
AquaLink® and Jandy® are trademarks of Jandy Industries, Inc. LT® and LX® are trademarks of Waterpik
Technologies, Inc. All other brand names, products names or trademarks belong to their respective holders.
SECTION 11.
Replacement Parts
11.1 Ordering Information
To order or purchase parts for the LX and LT
Low NOx pool and spa heater, contact your nearest
Jandy dealer or distributor. See the Jandy web site at
www.jandy.com for the nearest service center. If they
cannot supply you with what you need, contact
Customer Service at Waterpik Technologies, P.O. Box
6000, Petaluma, California, 94954, Telephone (707)
776-8200 extension 245.
NOTE: To supply the correct part it is important
that you state the model number, serial number
and type of gas when applicable. This
information is on the rating plate inside the
heater.
