21
3. Insert the thread between tension discs from the
right. Then pull both sides of thread.
3
Right needle thread tension dial
4. Turn the handwheel toward you to bring the
needle bar to its highest position, then pass the
thread through the right needle thread guide and
the thread take-up lever cover.
4
Right needle thread guide
5 Thread take-up lever cover
5. Pass the thread through the needle thread guide
sliding the thread from left to right.
6. Pass it through the needle bar thread guide from
left to right.
7. Thread the right needle from front to back and
pull the thread about 10 cm (4˝) from the eye of
the needle to the back.
6
Needle thread guide
7 Needle bar thread guide
8 Right needle
3
4
5 6 7
3
5
4
6
7
8
