Janome AirThread 2000D Professional - Right Needle to Plate Clearance

30
Adjusting Needle Bar Height
 The distance between the tip of the right needle (HA x 1SP#14) and
the surface of the needle plate should be between 11.6mm – 12.2mm
when the needle is at the highest position.
