Janome AirThread 2000D Professional - Adjust Sub Feed Dog (3.0 mm Screw); Adjust Front Feed Dog (2.0 mm Screw)

37
Adjusting Sub(Front) Feed Dogs
 Remove the needle plate. Locate the 3.0mm hexagon screw. If an
adjustment is needed, loosen the screw then raise or lower the feed
dog as needed. Tighten the 3.0mm hexagon screw.
 If an adjustment is needed, loosen the 2.0mm screw then using a
2.0mm hexagon wrench, turn the 2.0mm adjusting screw
clockwise to raise the feed dog or counterclockwise to lower the
feed dog . Tighten the 2.0mm screw.
2.0mm screw
2.0mm adjusting screw
Adjusting Main(Rear) Feed Dogs
