Janome AirThread 2000D Professional - Page 87

87
Reinstalling Motor, Machine Socket
Unit and C Board
 If it becomes necessary to replace the C board, using a hexagon nut
driver remove the 2 nuts from the machine socket unit. Disconnect
the C board terminals, then remove the C board.
 Reconnect the white harness. Reconnect the terminals, tighten the
2 nuts.
