JAROLIFT TDRRT-01W - Technical Data and Included Delivery; Electrical Connection

Technical data & included with delivery 2
2
Technical data & included with delivery
Technical data
230 V, 50 Hz
< 400 W
1 Watt
IP 20
-0°C to + 60°C
Rolling code
433.92 MHz
The receiver can store a maximum of 30 transmitting channels
Compatible with all TDR radio transmitters, as of production date 03/2010
Once you have unpacked the unit, compare the con-
tent of the package with the information provided in
these instructions about the scope of delivery:
1. Plastic support frame
2. Clock module, white
3. Outer frame, white
+ Instructions
1.5 mm
4 minutes
1
3
2
Electrical connection
M
Only authorised electricians are permitted
to work on the power connections of the
wireless timer and all other electrical work. All
work must comply with the wiring diagrams
provided in these instructions
Always disconnect the power prior to instal-
ling or connecting any electrical equipment.
Any work on electrical equipment carries the risk
of fatal injury from electric shock.
Motor
brown
black
blue
green/yellow
PE
N
L
1
L1
N
N
Power supply:
System load:
Standby consumption:
Protection:
max. authorised ambient temperature:
Radio coding:
Radio frequency:
Channels:
Compatibility:
Single-core connection cross section:
Power-on time:
