JAROLIFT TDRRT-01W - Programming the Radio Transmitter; Programming the Radio Code; Copying an Existing Radio Code; Deleting the Radio Code

Programming the radio transmitter 4
4
Programming the radio code
Using the radio receiver timer TDRRT-01W, you can convert a simple tubular motor into a convenient wireless motor in no time. The motor can then be
controlled remotely using any of the Jarolift TDR radio transmitters available. In addition, the timer feature an integrated clock for the automatic control of
the motor, as well as buttons for manual operation on-site.
Each button on the hand-held transmitter must be pressed for approx. 1 second!
(Motor vibrates)
Press the UP / DOWN but-
tons at the same time
then press the STOP
button
(Motor vibrates)
Press the STOP
button for 3
seconds
Copying an existing radio code (only when a transmitter has been programmed)
1.
Press the UP and DOWN buttons at the same time on the transmitter already programmed. Then press the STOP button on this transmitter
eight times. The motor will vibrate brie y as con rmation.
2.
Within 5 seconds, simultaneously press the UP and DOWN button on the transmitter onto which the code should be copied and then press
the STOP button brie y. The motor will vibrate brie y again as con rmation. The code has been copied to the new transmitter.
Press the UP / DOWN but-
tons at the same time
then press the STOP
button 8x
Transmitter 1
(Motor vibrates)
Press the UP / DOWN but-
tons at the same time
then press the STOP
button
Transmitter 2
(Motor vibrates)
Deleting the radio code (only when a transmitter has been programmed)
1.
Press the UP and DOWN buttons on the transmitter at the same time. Then press the STOP button six times.
2.
Now press the UP button inside 5 seconds. The motor will con rm the code has been deleted by vibrating brie y.
Press the UP / DOWN but-
tons at the same time
then press the STOP
button 6x
Press the UP button
(Motor vibrates)
