Pinout and Sync
Frequencies
Analog Color Display Pinouts (DB 15)
PIN FUNCTION
1
Red Video
1
2
Green Video
1
3
Blue Video
1
4 Not Used
5 Ground
6 Red Return (ground)
7 Green Return (ground)
8 Blue Return (ground)
9 Vcc (+5v DDC Power)
10 Sync Return (ground)
11 Monitor ID (not used)
12 SDA (DDC support)
13 Horizontal Sync
14 Vertical Sync
15 SCL (DDC support)
Note: Analog monochrome type monitors use green video for all
video input and ignore red and blue video.
Conversion Table: Pin Adapters
If you will be using a 9-to-15-pin adapter cable to link your 9-pin
monitor connector to the 15-pin accelerator card connector, check
Table carefully before you install the cable. The 9-to-15 pin adapter
cables are available from a variety of sources, but they need to match
the specifications in Table to work properly with your new card.
The adapter cable requires a D-shaped 9 pin female connector and a
D-shaped 15 pin male connector.
33
